Station Indoor Full Color LED Display P3 Airport Large LED Display Screen 192*192mm
|Place of Origin:||Guangdong, China (Mainland)|
|Certification:||CCC FC CE FC CB ROHS|
|Model Number:||Indoor P3 full color led module|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 pcs / 1 sqm|
|Packaging Details:||Carton，Honeycomb box，Wooden box，Flight Case|
|Delivery Time:||7-12 working days after received your payment|
|Payment Terms:||T/T, Western Union, MoneyGram|
|Supply Ability:||5000 Square Meters per Month|
|Brand Name:||Indoor Full Color LED Display||Best View Distance:||≥3m|
|Module Size:||192*192mm||Module Resolution:||64x64 Dots|
|Refresh Rate:||≥1920HZ||Pixel Configuration:||1R1G1B|
Station Indoor Full Color LED Display,
384*192mm Station Indoor Full Color LED Display,
P6 Large LED Display Screen
Indoor full color P3 station and airport passenger guidance LED display large screen
|Indoor full color LED display|
|Density of pixel/(dots/m2)||111,111||62,500||62,500|
|Resolution of module||64*64||60*30||64*32|
|Optimum viewing distance||3-50m||4-50m||4-50m|
|View angle / °||140H,120V||140H,120V||140H,120V|
|Refresh rate Hz/S||≥1920||≥1920||≥1920|
|Luminance of white balance||550nits||550nits||550nits|
|Operation of Environmental Temperature/℃||Below 50 -above 10|
|Working voltage||110-220 VAC/+/- 10%|
|Grey scale/color||displaying colors≥16.7M(synchronized)|
|Brightness adjustment||256 levels of each color(manually),100 levels of each color(automatically)|
|Control system||(sending card,receiving cards and Hubs)|
|Average of non-failure life||>50,00h|
|Functionless dot rate||<0.0001|
The introdution of indoor full-color display product:
1. advanced and reasonable system design, stable display effect, convenient installation and maintenance, ultra-high definition and ultra-high resolution.
2. All weather work: vivid color, high refresh frequency, anti-static, dust-proof, good heat dissipation effect and high cost performance.
3. Display mode: left and right movement, up and down movement, left pull screen, right pull screen, middle opening and closing, flashing, instant display and other modes.
4. Using the program editing and playing software, you can edit, add, delete and modify text, graphics, images and other information through the mouse. The content of the arrangement is stored in the control card, and the information is displayed automatically according to the program list. 5. Strong luminous brightness: within the visual distance, when the sun shines directly on the screen surface, the display content is still clearly visible.
6. Good viewing angle: there is a large viewing angle both horizontally and vertically, which is suitable for the environment with wide horizontal distribution and large height drop.
7. Good effect: using nonlinear point by point correction technology, the text is clearer and the sense of hierarchy is stronger;
8. Strong reliability: distributed scanning technology and modular design technology are adopted, with higher reliability and stability;
9. Diversified display modes: support multiple display modes;
10. Convenient operation: the edited content of the computer can be displayed when it is sent to the system control card. The system operation is very convenient.
2. No fans, mute when operation.
3. Dustproof, IP43.
4. High refresh rate and high gray depth.
5. Completely black LED with high contrast.
6. Standard cabinet size is 500mm x 500mm and 480x480mm.
7. Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.
8. Exactly connected and easy to install and dismount.
Packaging And Shipping
Wooden case or flight is available, customer can choose according to their requirement.
1. How can I get the price?
- We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). -If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote."
2. What is your lead time?
- It depends on the order quantity and the season you place the order. -Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
3. What is your payment term?
- EX factory price, 30% deposit, 70%T/T payment before shipment.
4. What is the shipping method?
- It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).Please confirm with us before placing orders.
