P1.53 Indoor Led Video Wall Display Panel For Monitoring Security Center
|Place of Origin:||Guangdong, China (Mainland)|
|Certification:||CCC FC CE FC CB ROHS|
|Model Number:||Indoor P1.53 full color led module|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 pcs / 1 sqm|
|Packaging Details:||Carton，Honeycomb box，Wooden box，Flight Case|
|Delivery Time:||7-12 working days after received your payment|
|Payment Terms:||T/T, Western Union, MoneyGram|
|Supply Ability:||5000 Square Meters per Month|
|Brand Name:||Indoor P1.53 Full Color LED Display||Pitch:||1.53mm|
|Module Size:||320*160mm||Module Resolution:||208x104 Dots|
|Density:||422500 Dots/sqm||Protection Level:||IP31|
|Drive Type:||1/26 Scan||Brightness:||550cd/sqm|
|Pixel Configuration:||1R1G1B||Refresh Rate:||≥3840HZ|
P1.53 Indoor Led Video Wall,
Monitoring Indoor Led Video Wall,
IP31 led display panel
Monitoring and security center p1.53 indoor small spacing full color display
|ITEM P1.53||Technical parameter|
|Drive type||1/26 Scanning|
|Optimum Viewing Distance(m)||2m|
|Max power consumption||875W/㎡|
|Ave power consumption||292W/㎡|
|Working Temperature||-20℃ to +60℃|
|Display Card||DVI Graphics|
The introdution of indoor full-color display product:
1. advanced and reasonable system design, stable display effect, convenient installation and maintenance, ultra-high definition and ultra-high resolution.
2. All weather work: vivid color, high refresh frequency, anti-static, dust-proof, good heat dissipation effect and high cost performance.
3. Display mode: left and right movement, up and down movement, left pull screen, right pull screen, middle opening and closing, flashing, instant display and other modes.
4. Using the program editing and playing software, you can edit, add, delete and modify text, graphics, images and other information through the mouse. The content of the arrangement is stored in the control card, and the information is displayed automatically according to the program list. 5. Strong luminous brightness: within the visual distance, when the sun shines directly on the screen surface, the display content is still clearly visible.
6. Good viewing angle: there is a large viewing angle both horizontally and vertically, which is suitable for the environment with wide horizontal distribution and large height drop.
7. Good effect: using nonlinear point by point correction technology, the text is clearer and the sense of hierarchy is stronger;
8. Strong reliability: distributed scanning technology and modular design technology are adopted, with higher reliability and stability;
9. Diversified display modes: support multiple display modes;
10. Convenient operation: the edited content of the computer can be displayed when it is sent to the system control card. The system operation is very convenient.
1. Video play: it can play video programs in video camera, VCD, DVD and LD; it can also play files of different formats, such as AVI, MOV, MPG, DAT and VOB; it has three display formats, namely, VGA+VIDE, Video and VGA;
2. Information release: it can display a variety of computer information, graphs, two-dimensional animation and three-dimensional animation; it has lots of display methods, such as rolling, lead-in, lead-out, up shift, left shift and circulation; font, character size, letter and speed can be set randomly;
3. Network function With the network interface, it can be connected with the Internet to play information on the Internet at the same time; display screens at different places can be centralizedly controlled through Internet according to customers’ requirements, and “VPM+broadband” may be adopted for remote control.
Packaging And Shipping
Wooden case or flight is available, customer can choose according to their requirement.
