Full Color Video HD 2K 4K Full Color Indoor outdoor LED Display Screen Customization
4K Full Color Indoor LED Display
,2K Full Color Indoor LED Display
Full Color Video HD 2K 4K Full Color Indoor outdoor LED Display Screen Customization
Product characteristics
1.Wireless connection
2.Ultra HD 2K/4K
3.Box weight (without kit and power supply):3kg
4.Box size (mm*mm):605*338 .5*29
5.Viewing Angle (H/V):H:160 V:160
6. Brightness (cd/㎡):300-600cd/㎡
7.Standard 16:9, 27-inch box, perfect for indoor ultra HD golden ratio
| Pixel spacing | 2mm | 2.5mm | 3mm | 4mm |
|---|---|---|---|---|
| LED Configuration | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density/sqm | 250000 dots | 160000 dots | 111111dots | 62500dots |
| Module Size/mm | 320*160 | 320*160 | 320*160 | 320*160 |
| Cabinet Size | 640x480mm | 640x480mm | 640x480mm | 640x480mm |
| Cabinet Resolution | 320x 240dots | 256x 192dots | 212x159dots | 160x120dots |
| IP Rating | IP31 | IP31 | IP31 | IP31 |
| Brightness /sqm | 600-1200 nits | 600-1200 nits | 600-1200 nits | 600-1200 nits |
| View Angle° | 160°/ 140°(HM) | 160°/ 140°(HM) | 160°/ 140°(HM) | 160°/ 140°(HM) |
| Gray Scale/bit | 16 bit | 16 bit | 16 bit | 16 bit |
| Max. Power ConsumptionW | 440 W/sqm | 440 W/sqm | 525 W/sqm | 475 W/sqm |
| Ave. Power ConsumptionW | 140 W/sqm | 145 W/sqm | 175W/sqm | 150 W/sqm |
| Refresh Frequency/Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz |
| Operating Power | AC 96~242V 50/60Hz | |||
| Operating Temperature | -40"C ~+60"C | |||
| Operating Humidity | 10~90%RH | |||
| Operating Life | 100000Hours | |||
Outdoor school square p8 full color LED display wateproof box large screen Specification ITEM P8 Technical parameter Module Module Dimension (W)256mm*128mm(H) Pixel pitch 8mm Pixel Density 15625 dots/㎡ Pixel configuration 1R1G1B LED specification SMD3535 Pixel resolution (W)32*16(H) resolution 512dots Current 3.5-4A Drive type 1/4 Scanning Refresh frequency ≥3840HZ Brightness 5500cd/㎡ Optimum Viewing Distance(m) 8~60m Max power consumption 800W/㎡ Ave power consumption 350W/㎡
LED outdoor p6 full color display bulletin board publicity square school park Specification ITEM P6 Technical parameter Module Module Dimension (W)192mm*192mm(H) Pixel pitch 6mm Pixel Density 27777 dots/㎡ Pixel configuration 1R1G1B LED specification SMD3535 Pixel resolution (W)32*32(H) resolution 1024dots Current 3.5-4A Drive type 1/8 Scanning Refresh frequency ≥3840HZ Brightness 5500cd/㎡ Optimum Viewing Distance(m) 6~40m Max power consumption 800W/㎡ Ave power consumption
P3 outdoor electronic display stadium scoring waterproof box multimedia advertising Specification ITEM P3 Technical parameter Module Module Dimension (W)192mm*192mm(H) Pixel pitch 3mm Pixel Density 111111pixels/㎡ Pixel configuration 1R1G1B LED specification SMD1921 Pixel resolution (W)64*64(H) resolution 4096dots Current 3.5-4A Drive type 1/16 Scanning Refresh frequency ≥3840HZ Brightness 5500cd/㎡ Optimum Viewing Distance(m) 3~20m Max power consumption 800W/㎡ Ave power
Rental Led display P2.976 full color indoor studio center meeting room Specification ITEM P2.976 Technical parameter Module Module Dimension (W)250mm*250mm(H) Pixel pitch 2.976mm Pixel Density 112896pixels/M2 Pixel configuration 1R1G1B LED specification HS/HG2020RGB Pixel resolution (W)84*84(H) resolution 7056dots Current 3.5-4A Drive type 1/28 Scanning Refresh frequency ≥3840HZ Brightness 600cd/ M2 Optimum Viewing Distance(m) 3-15m Max power consumption 665W/㎡ Ave power
