Product Details
Place of Origin: China
Brand Name: CanYi
Certification: CCC CB
Model Number: CanYi-P2.604
Payment & Shipping Terms
Minimum Order Quantity: 1 PCS /1 sqm
Price: Negotiation
Packaging Details: Carton,Honeycomb box, Wooden box, Flight Case
Delivery Time: 7-12 working days after received your payment
Payment Terms: T/T
Supply Ability: T/T Western Union, MoneyGram
Panel Size: |
Customize |
Usage Scenario: |
Indoor And Outdoor |
Brightness: |
High Definition |
Model Number: |
CanYi-P2.604 |
Size: |
500*1000 |
Panel: |
Panel Well |
Product Name: |
Led Display Screen |
Color: |
Full Color |
Humidity: |
5-20m |
Pixel Configuration: |
1R 1G 1B |
Panel Size: |
Customize |
Usage Scenario: |
Indoor And Outdoor |
Brightness: |
High Definition |
Model Number: |
CanYi-P2.604 |
Size: |
500*1000 |
Panel: |
Panel Well |
Product Name: |
Led Display Screen |
Color: |
Full Color |
Humidity: |
5-20m |
Pixel Configuration: |
1R 1G 1B |
Shopping Mall Support Customization Commercial LeoAdvertising Outdoor Screen Display
1.A LED video wall is a display system consisting of multiple LED panels, usually arranged in a grid or matrix pattern, that work together to create a larger, seamless image or video display. The panels are made up of numerous small LED (light-emitting diode) lights, which emit bright, vibrant colors and can be controlled to display different images or videos.
2.LED video walls are commonly used for outdoor advertising, sports stadiums, music concerts, and other large-scale events where a high-quality and visually striking display is required. They are also used in indoor settings such as conference rooms, retail stores, and museums to create immersive and interactive experiences.
3.The benefits of LED video walls include their high brightness, low power consumption, and long lifespan compared to traditional display technologies. They are also highly customizable, allowing for the creation of unique and eye-catching displays.
4.LED video walls are available in a range of sizes, resolutions, and pixel pitches to suit different applications and budgets. They can be controlled using specialized software and hardware, and can be easily integrated with other audiovisual systems.
| Pixel spacing | 2.5mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
| LED Configuration | SMD1515 | SMD1515 | SMD2525 | SMD2525 | SMD2525 | SMD3535 | SMD3535 |
| Pixel Density/sqm | 160000 dots | 111111dots | 62500dots | 40000dots | 27777dots | 15625dots | 10000dots |
| Module Size/mm | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
| Cabinet Size | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm |
| Cabinet Resolution | 384x 384dots | 312x 312dots | 240x240dots | 192x192dots | 159x159dots | 120x120dots | 96x96dots |
| IP Rating | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Brightness /sqm | 4000~8000 nits | 4000~8000 nits | 4000~8000 nits | 4000~8000 nits | 4000~8000 nits | 4000~8000 nits | 4000~8000 nits |
| View Angle° | 140°(HM) | 140°(HM) | 140°(HM) | 140°(HM) | 140°(HM) | 140°(HM) | 140°(HM) |
| Gray Scale/bit | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit |
| Max. Power ConsumptionW | 860 W/sqm | 786W/sqm | 840 W/sqm | 750 W/sqm | 790 W/sqm | 549 W/sqm | 650 W/sqm |
| Ave. Power ConsumptionW | 260W/sqm | 235W/sqm | 252W/sqm | 225 W/sqm | 238 W/sqm | 160 W/sqm | 230 W/sqm |
| Refresh Frequency/Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz | 1920~3840 Hz |
| Operating Power | AC 96~242V 50/60Hz | ||||||
| Operating Temperature | -40"C ~+60"C | ||||||
| Operating Humidity | 10~90%RH | ||||||
| Operating Life | 100000Hours | ||||||
