Home > products > Floor Tile Screen > Pressure-Resistant P4.81 Outdoor LED Display With Built-In Interactive Induction Floor Tile Screen

Pressure-Resistant P4.81 Outdoor LED Display With Built-In Interactive Induction Floor Tile Screen

Product Details

Place of Origin: China

Brand Name: CanYi

Certification: CCC CB ROHS

Model Number: CanYi-4.81

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiation

Packaging Details: Carton,Honeycomb box, Wooden box, Flight Case

Delivery Time: 7-12 working days after received your payment

Payment Terms: T/T, Western Union, MoneyGram

Supply Ability: 3000 Square Meters per Month

Get Best Price
Highlight:
Panel Size:
Customize
Usage Scenario:
Outdoor Floor
Brightness:
High Definition
Model Numb:
CanYi-p4.81
Size:
250×250X15mm
Panel:
Customized
Product Name:
Floor Tile Screen
Color:
Full Color
Humidity:
7-20m
Pixel Configuration:
1R 1G 1B
Panel Size:
Customize
Usage Scenario:
Outdoor Floor
Brightness:
High Definition
Model Numb:
CanYi-p4.81
Size:
250×250X15mm
Panel:
Customized
Product Name:
Floor Tile Screen
Color:
Full Color
Humidity:
7-20m
Pixel Configuration:
1R 1G 1B
Pressure-Resistant P4.81 Outdoor LED Display With Built-In Interactive Induction Floor Tile Screen

Pressure-Resistant P4.81 Outdoor LED Display With Built-In Interactive Induction Floor Tile Screen



Introducing the Revolutionary Pressure-Resistant P4.81 Outdoor LED Display with Built-In Interactive Induction Floor Tile Screen

In today's rapidly evolving technological landscape, businesses are constantly searching for innovative ways to engage and captivate their audience. The Pressure-Resistant P4.81 Outdoor LED Display with Built-In Interactive Induction Floor Tile Screen is here to revolutionize the world of advertising and entertainment.

This cutting-edge LED display combines the power of visual excellence with interactive technology, creating an immersive experience that will leave a lasting impression on your customers. With a pixel pitch of just 4.81mm, this display delivers stunning picture quality, ensuring that every image and video displayed is sharp, vibrant, and crystal clear.

One of the standout features of this LED display is its built-in interactive induction floor tile screen. By incorporating touch-sensitive technology into the floor tiles, users can engage with the content in a whole new way. Whether it's a playful game, interactive advertisement, or informative display, the interactive floor tiles offer endless possibilities for creativity and engagement.

Furthermore, the pressure-resistant design of this outdoor LED display ensures durability and reliability even in harsh weather conditions. It is specially engineered to withstand high-pressure environments, making it suitable for outdoor installations in bustling city centers or sports stadiums.

The flexibility of this LED display allows for easy installation and customization. It can be seamlessly integrated into any environment, adapting to various architectural structures and layouts. Its modular design enables scalability, allowing you to expand or reduce the display size as per your requirements.

Not only does the Pressure-Resistant P4.81 Outdoor LED Display offer stunning visual appeal, but it also provides excellent energy efficiency. Equipped with advanced LED technology, it consumes significantly less power compared to traditional display solutions, helping you to reduce operational costs and contribute to a greener environment.

Whether you are a business owner looking to enhance your brand presence or an event organizer aiming to create unforgettable experiences, the Pressure-Resistant P4.81 Outdoor LED Display with Built-In Interactive Induction Floor Tile Screen is the perfect solution. With its exceptional visual quality, interactive capabilities, durability, and energy efficiency, this display is set to redefine the way we engage with digital content.

Experience the future of advertising and entertainment with the Pressure-Resistant P4.81 Outdoor LED Display. Prepare to captivate your audience and leave a lasting impression that will set you apart from the competition.



serial number name project Technical indicators
1 LED tube Lamp bead shape SMD1 921
2 Pixel composition Arrangement Vertical
3   Pixel tube spacing 4.81mm _
4   Pixel composition 1R1G1B
5   Primary color composition The three primary colors of red, green and blue
6   physical density 43264 points/㎡
7

module

Cabinet size

Module size 250×250X15 mm high (length x width x thickness)
8   Module resolution 52 width × 52 height (points)
9   Cabinet size Iron box foot installation 1000x500mm
10   out of control point ≤4/100000
11   Unit module seams The joint size of the unit board gaps is consistent and ≤1 mm
12   optimal distance 7-20m
13   perspective 120° horizontally, 120° vertically
14   Surface roughness Maximum error≤1 mm
15   Screen surface ink color Ink color consistent
16   Uniformity Module brightness is uniform
17 Usage environment ambient temperature -20°~50°
18   Relative humidity 25°~95°
19 powered by Input voltage (AC) 220V,±10%
20   Leakage current to earth < 3Ma
twenty one   input frequency 50/60HZ
twenty two   average power 3 5 0W/㎡
twenty three   Peak power 800W/㎡
25   control method Sync with computer VGA (monitor sync)
26   Control System DVI graphics card + full color control card + optical fiber transmission
27   Input Computers and other peripherals, VGA, HDMI, DVI, etc.
29   Refresh frequency 1920hz
30   Grayscale/Color Level 8192
31   Whole screen brightness 35 00cd/㎡
32   Service life More than 100,000 hours
33   Display content Video DVD, VCD, TV, images, text, animation, and others.
34   Continuous trouble-free working time ≥10000 hours
35   interface Standard Ethemer network interface (Gigabit)
36   Communication medium, control distance Multimode optical fiber <500m, single-mode optical fiber transmission <30km, Category 5 line <100m
37   protection technology Waterproof, moisture-proof, dust-proof, anti-corrosion, anti-static, lightning-proof, and has over-current/short circuit, over-voltage, and under-voltage protection functions
